KAC-128AD2 & 158AD2

Active speaker with digital amplifier

The KAC Series two-way active loudspeaker is a first-class choice when it comes to providing your events with precise treble and powerful bass. A powerful 600W/1000W bi-amping digital amplifier drives the 12"/15" woofer (High class Neodymium) and 1.75"/3"VC high-frequency driver excellently. The pre-installed DSP sound modes give the KAC Series a wide range of possible applications, such as for FOH indoor/outdoor, Monitor in stage, DJ in club and Speech in meeting. The DSP also provides an Ethernet connector to link the PC. Customers can create their own favorite presets from PC by EQ adjustment, three choices as User1,User2 and User3. Thanks to the use of Neodymium magnets in the bass, the KAC Series is very powerful but light to carry. Attractive aesthetic design, inserted rib for extra reinforcement and special full embedded grill for durable usage. The recessed front panel into back housing offers the necessary cabinet stability. Built-in protection circuits guarantee a robust and stable partner at your side too.

Features: (1) UCD Bi-amp (2) Built-in High Quality Tunable DSP with visual operation LCD display DSP processor, 64 Bits/48 kHz fast running and low noise. (3) Signal INPUT and OUTPUT Female XLR input(Bal/Unbal) and Male XLR signal output. (4) NEO Loudspeakers High efficiency, light weight, small size but high SPL. (5) MAX SPL 134/132dB MAX. (6) Clarity HF Drivers 1.75” VC/ 3” VC offers wide frequency range and high sensitivity. (7) Friendly ergonomic handles (8) Anti-shock, optimized thickened grill by powder coating. (9) Durable and light enclosure. (10) Parallel Usage AC power socket input and power supply output. (11) Multiple installation methods Pole-mount, Tripod, Stage Monitor or Suspended according to specific application

Thank you for your choice!

Technical specifications

KAC-128AD2

Components: 12" NEO woofer + 1.75" driver
Frequenzy response: 50 Hz - 20 kHz
RMS power: 600 W
Program Power: 1200 W
Dispasion (6dB): H90° x V60°
Max. SPL: 132 dB (W/1m)
Flying points: 2x M10
Connection: XLR
Product weight: 15.5 kg
Product size: 36.1 x 35.8 x 60.2 cm

Amplifier module

Output power: 2 x 350 W/4 ohm
S/N: > 95 dBA (A weighted)
Damping factor: > 500 (20Hz-100Hz)
Protection: over voltage protection up to 264V AC, overload output protection , clip , soft limiter

KAC-158AD2

Components: 15“ neo woofer + 3“ driver
Frequenzy response: 50 Hz - 20 kHz
RMS power: 1000 W
Program Power: 2000 W
Dispasion (6dB): H90° x V60°
Max. SPL: 134 dB (W/1m)
Flying points: 2x M10
Connection: XLR
Product weight: 22 kg
Product size: 41.7 x 38 x 69.4 cm

Amplifier module

Output power: 2 x 500 W/4 ohm
S/N: > 95 dBA (A weighted)
Damping factor: > 500 (20Hz-100Hz)
Protection: over voltage protection up to 264V AC, overload output protection , clip , soft limiter
